Microchip Technology LM2575-5.0YN
- Mfg. Part Number
- LM2575-5.0YN
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK 5V 1A 16DIP
- Datasheet Download
- LM2575-5.0YN.pdf
Availability of LM2575-5.0YN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.44000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM2575-5.0YN, we specialize in Microchip Technology all series electronic components. LM2575-5.0YN can be shipped within 24 hours after order. If you have any demands for LM2575-5.0YN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM2575-5.0YN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM2575-5.0YN
| Internal Part Number | EIS-LM2575-5.0YN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Troubleshooting Switching Power Supplies | |
| PCN Assembly/Origin | Wafer Size Update 02/Sep/2015 | |
| Standard Package | 25 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tube | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Fixed | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4V | |
| Voltage - Input (Max) | 40V | |
| Voltage - Output (Min/Fixed) | 5V | |
| Voltage - Output (Max) | - | |
| Current - Output | 1A | |
| Frequency - Switching | 52kHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | 16-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 16-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM2575-5.0YN | |
| Related Links | LM2575, LM2575-5.0YN Datasheet, Microchip Technology Distributor | |
LM2575-5.0YN Details Description
