Texas Instruments LM285LPR-2-5
- Mfg. Part Number
- LM285LPR-2-5
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SHUNT 2.5V TO92-3
- Datasheet Download
- LM285LPR-2-5.pdf
Availability of LM285LPR-2-5
Available Quantity
11020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.19250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM285LPR-2-5, we specialize in Texas Instruments all series electronic components. LM285LPR-2-5 can be shipped within 24 hours after order. If you have any demands for LM285LPR-2-5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM285LPR-2-5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM285LPR-2-5
| Internal Part Number | EIS-LM285LPR-2-5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Reference Type | Shunt | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 2.5V | |
| Voltage - Output (Max) | - | |
| Current - Output | 20mA | |
| Tolerance | ±1.5% | |
| Temperature Coefficient | 20ppm/°C Typical | |
| Noise - 0.1Hz to 10Hz | - | |
| Noise - 10Hz to 10kHz | 120µVrms | |
| Voltage - Input | - | |
| Current - Supply | - | |
| Current - Cathode | 20µA | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Through Hole | |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | |
| Supplier Device Package | TO-92-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM285LPR-2-5 | |
| Related Links | LM285L, LM285LPR-2-5 Datasheet, Texas Instruments Distributor | |
LM285LPR-2-5 Details Description
