Texas Instruments LM3017EVM
- Mfg. Part Number
- LM3017EVM
- Manufacturer
- Texas Instruments
- Product Category
- Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
- Brief Description
- EVAL BOARD FOR LM3017
- Datasheet Download
- LM3017EVM.pdf
Availability of LM3017EVM
Available Quantity
5023 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 49.38000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM3017EVM, we specialize in Texas Instruments all series electronic components. LM3017EVM can be shipped within 24 hours after order. If you have any demands for LM3017EVM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM3017EVM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM3017EVM
| Internal Part Number | EIS-LM3017EVM | |
| Lead Free Status / RoHS Status | Contains lead / RoHS compliant by exemption | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Series | - | |
| Main Purpose | DC/DC, Step Up | |
| Outputs and Type | 1, Non-Isolated | |
| Power - Output | - | |
| Voltage - Output | 15V | |
| Current - Output | 1A | |
| Voltage - Input | 8 V ~ 12 V | |
| Regulator Topology | Boost | |
| Frequency - Switching | 600kHz | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | LM3017 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM3017EVM | |
| Related Links | LM30, LM3017EVM Datasheet, Texas Instruments Distributor | |
LM3017EVM Details Description
