Texas Instruments LM4041DIM3X-ADJ
- Mfg. Part Number
- LM4041DIM3X-ADJ
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SHUNT ADJ SOT23-3
- Datasheet Download
- LM4041DIM3X-ADJ.pdf
Availability of LM4041DIM3X-ADJ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.32480
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM4041DIM3X-ADJ, we specialize in Texas Instruments all series electronic components. LM4041DIM3X-ADJ can be shipped within 24 hours after order. If you have any demands for LM4041DIM3X-ADJ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM4041DIM3X-ADJ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM4041DIM3X-ADJ
| Internal Part Number | EIS-LM4041DIM3X-ADJ | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Reference Type | Shunt | |
| Output Type | Adjustable | |
| Voltage - Output (Min/Fixed) | 1.233V | |
| Voltage - Output (Max) | 10V | |
| Current - Output | 12mA | |
| Tolerance | ±1% | |
| Temperature Coefficient | 150ppm/°C | |
| Noise - 0.1Hz to 10Hz | - | |
| Noise - 10Hz to 10kHz | 20µVrms | |
| Voltage - Input | - | |
| Current - Supply | - | |
| Current - Cathode | 70µA | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | |
| Supplier Device Package | SOT-23-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM4041DIM3X-ADJ | |
| Related Links | LM4041D, LM4041DIM3X-ADJ Datasheet, Texas Instruments Distributor | |
LM4041DIM3X-ADJ Details Description
