Texas Instruments LM4835MTE
- Mfg. Part Number
- LM4835MTE
- Manufacturer
- Texas Instruments
- Product Category
- Linear - Amplifiers - Audio
- Brief Description
- IC AMP AUDIO PWR 2.2W AB 28TSSOP
- Datasheet Download
- LM4835MTE.pdf
Availability of LM4835MTE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM4835MTE, we specialize in Texas Instruments all series electronic components. LM4835MTE can be shipped within 24 hours after order. If you have any demands for LM4835MTE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM4835MTE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM4835MTE
| Internal Part Number | EIS-LM4835MTE | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | LM4835MTE Material | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 48 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Audio | |
| Series | Boomer® | |
| Packaging | Tube | |
| Type | Class AB | |
| Output Type | 2-Channel (Stereo) with Stereo Headphones | |
| Max Output Power x Channels @ Load | 2.2W x 2 @ 3 Ohm; 95mW x 2 @ 32 Ohm | |
| Voltage - Supply | 2.7 V ~ 5.5 V | |
| Features | Depop, Mute, Shutdown, Thermal Protection, Volume Control | |
| Mounting Type | Surface Mount | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Supplier Device Package | 28-HTSSOP | |
| Package / Case | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM4835MTE | |
| Related Links | LM48, LM4835MTE Datasheet, Texas Instruments Distributor | |
LM4835MTE Details Description
