Texas Instruments LM5068MMX-1
- Mfg. Part Number
- LM5068MMX-1
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Hot Swap Controllers
- Brief Description
- IC CTLR HOT SWAP -48V 8VSSOP
- Datasheet Download
- LM5068MMX-1.pdf
Availability of LM5068MMX-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM5068MMX-1, we specialize in Texas Instruments all series electronic components. LM5068MMX-1 can be shipped within 24 hours after order. If you have any demands for LM5068MMX-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM5068MMX-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM5068MMX-1
| Internal Part Number | EIS-LM5068MMX-1 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Hot Swap Controllers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Hot Swap Controller | |
| Number of Channels | 1 | |
| Internal Switch(s) | No | |
| Applications | -48V | |
| Features | Latched Fault, Turn On Voltage | |
| Programmable Features | Circuit Breaker, Current Limit, Fault Timeout, OVP, UVLO | |
| Voltage - Supply | -90 V ~ -10 V | |
| Current - Output (Max) | - | |
| Operating Temperature | -40°C ~ 105°C | |
| Current - Supply | 820µA | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | |
| Supplier Device Package | 8-VSSOP | |
| Feature Pins | PWRGD, OV, TIMER, UV | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM5068MMX-1 | |
| Related Links | LM506, LM5068MMX-1 Datasheet, Texas Instruments Distributor | |
LM5068MMX-1 Details Description
