Texas Instruments LM71CIMFX
- Mfg. Part Number
- LM71CIMFX
- Manufacturer
- Texas Instruments
- Product Category
- Temperature Sensors, Transducers
- Brief Description
- SENSOR TEMPERATURE SPI SOT23-5
- Datasheet Download
- LM71CIMFX.pdf
Availability of LM71CIMFX
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM71CIMFX, we specialize in Texas Instruments all series electronic components. LM71CIMFX can be shipped within 24 hours after order. If you have any demands for LM71CIMFX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM71CIMFX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM71CIMFX
| Internal Part Number | EIS-LM71CIMFX | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Sensors, Transducers | |
| Family | Temperature Sensors, Transducers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Sensor Type | Digital, Local | |
| Sensing Temperature - Local | -40°C ~ 150°C | |
| Sensing Temperature - Remote | - | |
| Output Type | SPI | |
| Voltage - Supply | 2.65 V ~ 5.5 V | |
| Resolution | 13 b | |
| Features | Shutdown Mode | |
| Accuracy - Highest (Lowest) | 1.5°C (-2°C, 3°C) | |
| Test Condition | -10°C ~ 65°C (-40°C ~ 150°C) | |
| Operating Temperature | -40°C ~ 150°C | |
| Package / Case | SC-74A, SOT-753 | |
| Supplier Device Package | SOT-23-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM71CIMFX | |
| Related Links | LM71, LM71CIMFX Datasheet, Texas Instruments Distributor | |
LM71CIMFX Details Description
