Texas Instruments LM8300IMT9
- Mfg. Part Number
- LM8300IMT9
- Manufacturer
- Texas Instruments
- Product Category
- Data Acquisition - Touch Screen Controllers
- Brief Description
- IC TOUCHSCREEN CONTROLLR 48TSSOP
- Datasheet Download
- LM8300IMT9.pdf
Availability of LM8300IMT9
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM8300IMT9, we specialize in Texas Instruments all series electronic components. LM8300IMT9 can be shipped within 24 hours after order. If you have any demands for LM8300IMT9, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM8300IMT9 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM8300IMT9
| Internal Part Number | EIS-LM8300IMT9 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 38 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Touch Screen Controllers | |
| Series | - | |
| Packaging | Tube | |
| Type | Resistive | |
| Touch Panel Interface | 4-Wire | |
| Number of Inputs/Keys | 1 TSC | |
| Resolution (Bits) | 10 b | |
| Evaluation Tools | Available | |
| Data Interface | UART | |
| Data Rate/Sampling Rate (SPS, BPS) | 38.4k | |
| Voltage Reference | - | |
| Voltage - Supply | 2.7 V ~ 5.5 V | |
| Current - Supply | 11.5mA | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 48-TFSOP (0.240", 6.10mm Width) | |
| Supplier Device Package | 48-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM8300IMT9 | |
| Related Links | LM830, LM8300IMT9 Datasheet, Texas Instruments Distributor | |
