AVX Corporation LMIP2016M2R2AT1R
- Mfg. Part Number
- LMIP2016M2R2AT1R
- Manufacturer
- AVX Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.2UH 1.6A 160 MOHM
- Datasheet Download
- LMIP2016M2R2AT1R.pdf
Availability of LMIP2016M2R2AT1R
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LMIP2016M2R2AT1R, we specialize in AVX Corporation all series electronic components. LMIP2016M2R2AT1R can be shipped within 24 hours after order. If you have any demands for LMIP2016M2R2AT1R, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LMIP2016M2R2AT1R Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LMIP2016M2R2AT1R
| Internal Part Number | EIS-LMIP2016M2R2AT1R | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | LMIP | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Powdered Iron | |
| Inductance | 2.2µH | |
| Tolerance | ±20% | |
| Current Rating | 1.6A | |
| Current - Saturation | 1.55A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 160 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0806 (2016 Metric) | |
| Size / Dimension | 0.079" L x 0.063" W (2.00mm x 1.60mm) | |
| Height - Seated (Max) | 0.039" (1.00mm) | |
| Supplier Device Package | 0806 (2016 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LMIP2016M2R2AT1R | |
| Related Links | LMIP2016, LMIP2016M2R2AT1R Datasheet, AVX Corporation Distributor | |
LMIP2016M2R2AT1R Details Description
