Texas Instruments LP3872ESX-3.3/NOPB
- Mfg. Part Number
- LP3872ESX-3.3/NOPB
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 3.3V 1.5A DDPAK
- Datasheet Download
- LP3872ESX-3.3/NOPB.pdf
Availability of LP3872ESX-3.3/NOPB
Available Quantity
5520 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.55250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LP3872ESX-3.3/NOPB, we specialize in Texas Instruments all series electronic components. LP3872ESX-3.3/NOPB can be shipped within 24 hours after order. If you have any demands for LP3872ESX-3.3/NOPB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LP3872ESX-3.3/NOPB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LP3872ESX-3.3/NOPB
| Internal Part Number | EIS-LP3872ESX-3.3/NOPB | |
| Lead Free Status / RoHS Status | Contains lead / RoHS compliant by exemption | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Create your power design now with TI’s WEBENCH® Designer | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Regulator Topology | Positive Fixed | |
| Voltage - Output | 3.3V | |
| Current - Output | 1.5A | |
| Voltage - Dropout (Typical) | 0.38V @ 1.5A | |
| Number of Regulators | 1 | |
| Voltage - Input | Up to 7V | |
| Current - Limit (Min) | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA | |
| Supplier Device Package | DDPAK/TO-263-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LP3872ESX-3.3/NOPB | |
| Related Links | LP3872ESX, LP3872ESX-3.3/NOPB Datasheet, Texas Instruments Distributor | |
LP3872ESX-3.3/NOPB Details Description
