Murata Electronics North America LQP02TQ3N6C02D
- Mfg. Part Number
- LQP02TQ3N6C02D
- Manufacturer
- Murata Electronics North America
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 3.6NH 280MA 1 OHM SMD
- Datasheet Download
- LQP02TQ3N6C02D.pdf
Availability of LQP02TQ3N6C02D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.03200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LQP02TQ3N6C02D, we specialize in Murata Electronics North America all series electronic components. LQP02TQ3N6C02D can be shipped within 24 hours after order. If you have any demands for LQP02TQ3N6C02D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LQP02TQ3N6C02D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LQP02TQ3N6C02D
| Internal Part Number | EIS-LQP02TQ3N6C02D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Chip RF Inductors | |
| Standard Package | 20,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | LQP02TQ_02 | |
| Packaging | Tape & Reel (TR) | |
| Type | Thick Film | |
| Material - Core | - | |
| Inductance | 3.6nH | |
| Tolerance | ±0.2nH | |
| Current Rating | 280mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 1 Ohm Max | |
| Q @ Freq | 10 @ 500MHz | |
| Frequency - Self Resonant | 9.7GHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 500MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 01005 (0402 Metric) | |
| Size / Dimension | 0.016" L x 0.008" W (0.40mm x 0.20mm) | |
| Height - Seated (Max) | 0.009" (0.22mm) | |
| Supplier Device Package | 01005 (0402 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LQP02TQ3N6C02D | |
| Related Links | LQP02TQ, LQP02TQ3N6C02D Datasheet, Murata Electronics North America Distributor | |
LQP02TQ3N6C02D Details Description
