TT Electronics/IRC LRC-LR2512LF-01-R500F
- Mfg. Part Number
- LRC-LR2512LF-01-R500F
- Manufacturer
- TT Electronics/IRC
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 0.5 OHM 1% 2W 2512
- Datasheet Download
- LRC-LR2512LF-01-R500F.pdf
Availability of LRC-LR2512LF-01-R500F
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.28560
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LRC-LR2512LF-01-R500F, we specialize in TT Electronics/IRC all series electronic components. LRC-LR2512LF-01-R500F can be shipped within 24 hours after order. If you have any demands for LRC-LR2512LF-01-R500F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LRC-LR2512LF-01-R500F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LRC-LR2512LF-01-R500F
| Internal Part Number | EIS-LRC-LR2512LF-01-R500F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Current Sense Resistor Products | |
| RoHS Information | RoHS Cert of Compliance | |
| Standard Package | 1,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | LR | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 0.5 | |
| Tolerance | ±1% | |
| Power (Watts) | 2W | |
| Composition | Thick Film | |
| Features | Current Sense, Moisture Resistant | |
| Temperature Coefficient | ±100ppm/°C | |
| Operating Temperature | -55°C ~ 150°C | |
| Package / Case | 2512 (6432 Metric) | |
| Supplier Device Package | 2512 | |
| Size / Dimension | 0.256" L x 0.128" W (6.50mm x 3.25mm) | |
| Height | 0.033" (0.84mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LRC-LR2512LF-01-R500F | |
| Related Links | LRC-LR2512, LRC-LR2512LF-01-R500F Datasheet, TT Electronics/IRC Distributor | |
LRC-LR2512LF-01-R500F Details Description
