Honeywell Sensing and Productivity Solutions LSYAB6B-2D
- Mfg. Part Number
- LSYAB6B-2D
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Snap Action, Limit Switches
- Brief Description
- PLUG-INLOW TEMP VERS SIDE ROTARY
- Datasheet Download
- LSYAB6B-2D.pdf
Availability of LSYAB6B-2D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 205.76000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LSYAB6B-2D, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. LSYAB6B-2D can be shipped within 24 hours after order. If you have any demands for LSYAB6B-2D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LSYAB6B-2D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LSYAB6B-2D
| Internal Part Number | EIS-LSYAB6B-2D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | LSY | |
| Packaging | Bulk | |
| Circuit | DPDT-DB | |
| Switch Function | On-Mom | |
| Current Rating | 10A (AC), 800mA (DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 115V | |
| Actuator Type | Side Rotary, Adjustable Roller | |
| Mounting Type | Chassis Mount | |
| Termination Style | Plug In | |
| Ingress Protection | - | |
| Features | Steel Roller, Front Mounted | |
| Operating Force, Torque | 4 in-lb | |
| Release Force | - | |
| Pretravel | 15° | |
| Differential Travel | 7° | |
| Overtravel | 60° | |
| Operating Position | - | |
| Mechanical Life | - | |
| Electrical Life | - | |
| Operating Temperature | -40°C ~ 121°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LSYAB6B-2D | |
| Related Links | LSYAB, LSYAB6B-2D Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
