Linear LT1336IN#PBF
- Mfg. Part Number
- LT1336IN#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC MOSFET DRVR 1/2BRDG NCH 16DIP
- Datasheet Download
- LT1336IN#PBF.pdf
Availability of LT1336IN#PBF
Available Quantity
5366 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.70000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LT1336IN#PBF, we specialize in Linear all series electronic components. LT1336IN#PBF can be shipped within 24 hours after order. If you have any demands for LT1336IN#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LT1336IN#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LT1336IN#PBF
| Internal Part Number | EIS-LT1336IN#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Configuration | Half Bridge | |
| Input Type | Differential | |
| Delay Time | 250ns | |
| Current - Peak | 1.5A | |
| Number of Configurations | 1 | |
| Number of Outputs | 2 | |
| High Side Voltage - Max (Bootstrap) | 60V | |
| Voltage - Supply | 10 V ~ 15 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Through Hole | |
| Package / Case | 16-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 16-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LT1336IN#PBF | |
| Related Links | LT1336, LT1336IN#PBF Datasheet, Linear Distributor | |
LT1336IN#PBF Details Description
