Linear LT1961EMS8E#TR
- Mfg. Part Number
- LT1961EMS8E#TR
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG MULT CONFG ADJ 1.5A 8MSOP
- Datasheet Download
- LT1961EMS8E#TR.pdf
Availability of LT1961EMS8E#TR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.85925
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LT1961EMS8E#TR, we specialize in Linear all series electronic components. LT1961EMS8E#TR can be shipped within 24 hours after order. If you have any demands for LT1961EMS8E#TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LT1961EMS8E#TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LT1961EMS8E#TR
| Internal Part Number | EIS-LT1961EMS8E#TR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Up, Step-Up/Step-Down | |
| Output Configuration | Positive | |
| Topology | Boost, Flyback, SEPIC | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 3V | |
| Voltage - Input (Max) | 25V | |
| Voltage - Output (Min/Fixed) | 1.2V | |
| Voltage - Output (Max) | 35V (Switch) | |
| Current - Output | 1.5A (Switch) | |
| Frequency - Switching | 1.25MHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | |
| Supplier Device Package | 8-MSOP-EP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LT1961EMS8E#TR | |
| Related Links | LT1961E, LT1961EMS8E#TR Datasheet, Linear Distributor | |
LT1961EMS8E#TR Details Description
