Linear LT3091HR#PBF
- Mfg. Part Number
- LT3091HR#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO NEG AD 1.5A
- Datasheet Download
- LT3091HR#PBF.pdf
Availability of LT3091HR#PBF
Available Quantity
5070 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.34660
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LT3091HR#PBF, we specialize in Linear all series electronic components. LT3091HR#PBF can be shipped within 24 hours after order. If you have any demands for LT3091HR#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LT3091HR#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LT3091HR#PBF
| Internal Part Number | EIS-LT3091HR#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tube | |
| Regulator Topology | Negative Adjustable | |
| Voltage - Output | 0 V ~ -32 V | |
| Current - Output | 1.5A | |
| Voltage - Dropout (Typical) | 0.36V @ 1.5A | |
| Number of Regulators | 1 | |
| Voltage - Input | -1.5 V ~ -36 V | |
| Current - Limit (Min) | - | |
| Operating Temperature | -40°C ~ 150°C | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-8, D²Pak (7 Leads + Tab), TO-263CA | |
| Supplier Device Package | 7-DDPAK | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LT3091HR#PBF | |
| Related Links | LT3091, LT3091HR#PBF Datasheet, Linear Distributor | |
LT3091HR#PBF Details Description
