Linear LT3477EFE#TRPBF
- Mfg. Part Number
- LT3477EFE#TRPBF
- Manufacturer
- Linear
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver DC DC Regulator PWM Dimming 3A (Switch) 20-TSSOP-EP
- Datasheet Download
- LT3477EFE#TRPBF.pdf
Availability of LT3477EFE#TRPBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.98000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LT3477EFE#TRPBF, we specialize in Linear all series electronic components. LT3477EFE#TRPBF can be shipped within 24 hours after order. If you have any demands for LT3477EFE#TRPBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LT3477EFE#TRPBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LT3477EFE#TRPBF
| Internal Part Number | EIS-LT3477EFE#TRPBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | DC DC Regulator | |
| Topology | Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost) | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 1 | |
| Voltage - Supply (Min) | 2.5V | |
| Voltage - Supply (Max) | 25V | |
| Voltage - Output | - | |
| Current - Output / Channel | 3A (Switch) | |
| Frequency | 200kHz ~ 3.5MHz | |
| Dimming | PWM | |
| Applications | - | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) Exposed Pad | |
| Supplier Device Package | 20-TSSOP-EP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LT3477EFE#TRPBF | |
| Related Links | LT3477E, LT3477EFE#TRPBF Datasheet, Linear Distributor | |
LT3477EFE#TRPBF Details Description
