Linear LTC1154CS8#PBF
- Mfg. Part Number
- LTC1154CS8#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC MOSFET DRIVER HIGH-SIDE 8SOIC
- Datasheet Download
- LTC1154CS8#PBF.pdf
Availability of LTC1154CS8#PBF
Available Quantity
6945 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC1154CS8#PBF, we specialize in Linear all series electronic components. LTC1154CS8#PBF can be shipped within 24 hours after order. If you have any demands for LTC1154CS8#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC1154CS8#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC1154CS8#PBF
| Internal Part Number | EIS-LTC1154CS8#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Configuration | High-Side | |
| Input Type | Non-Inverting | |
| Delay Time | 160µs | |
| Current - Peak | - | |
| Number of Configurations | 1 | |
| Number of Outputs | 1 | |
| High Side Voltage - Max (Bootstrap) | - | |
| Voltage - Supply | 4.5 V ~ 18 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC1154CS8#PBF | |
| Related Links | LTC1154, LTC1154CS8#PBF Datasheet, Linear Distributor | |
LTC1154CS8#PBF Details Description
