Linear LTC1644IGN#TR
- Mfg. Part Number
- LTC1644IGN#TR
- Manufacturer
- Linear
- Product Category
- PMIC - Hot Swap Controllers
- Brief Description
- IC CONTROLLER HOT SWAP 20-SSOP
- Datasheet Download
- LTC1644IGN#TR.pdf
Availability of LTC1644IGN#TR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.62300
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC1644IGN#TR, we specialize in Linear all series electronic components. LTC1644IGN#TR can be shipped within 24 hours after order. If you have any demands for LTC1644IGN#TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC1644IGN#TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC1644IGN#TR
| Internal Part Number | EIS-LTC1644IGN#TR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Hot Swap Controllers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Hot Swap Controller | |
| Number of Channels | 4 | |
| Internal Switch(s) | Both | |
| Applications | CompactPCI™ | |
| Features | Latched Fault, Thermal Limit, UVLO | |
| Programmable Features | Current Limit, Fault Timeout | |
| Voltage - Supply | 3.3V, 5V, ±12V | |
| Current - Output (Max) | 100mA, 500mA | |
| Operating Temperature | -40°C ~ 85°C | |
| Current - Supply | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-SSOP (0.154", 3.90mm Width) | |
| Supplier Device Package | 20-SSOP | |
| Feature Pins | DRIVE, /FAULT, (OFF, /ON), PRECHARGE, /PWRGD, /RESETIN, /RESETOUT, TIMER | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC1644IGN#TR | |
| Related Links | LTC164, LTC1644IGN#TR Datasheet, Linear Distributor | |
LTC1644IGN#TR Details Description
