Linear LTC2301IDE#TRPBF
- Mfg. Part Number
- LTC2301IDE#TRPBF
- Manufacturer
- Linear
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 12-BIT 1CHN 12-DFN
- Datasheet Download
- LTC2301IDE#TRPBF.pdf
Availability of LTC2301IDE#TRPBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.94001
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC2301IDE#TRPBF, we specialize in Linear all series electronic components. LTC2301IDE#TRPBF can be shipped within 24 hours after order. If you have any demands for LTC2301IDE#TRPBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC2301IDE#TRPBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC2301IDE#TRPBF
| Internal Part Number | EIS-LTC2301IDE#TRPBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | General Purpose SAR ADCs | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Bits | 12 | |
| Sampling Rate (Per Second) | 14k | |
| Number of Inputs | 1 | |
| Input Type | Differential, Single Ended | |
| Data Interface | I²C | |
| Configuration | MUX-S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 1 | |
| Architecture | SAR | |
| Reference Type | External, Internal | |
| Voltage - Supply, Analog | 5V | |
| Voltage - Supply, Digital | 5V | |
| Features | Selectable Address | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 12-WFDFN Exposed Pad | |
| Supplier Device Package | 12-DFN (4x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC2301IDE#TRPBF | |
| Related Links | LTC2301I, LTC2301IDE#TRPBF Datasheet, Linear Distributor | |
LTC2301IDE#TRPBF Details Description
