Linear LTC2424IG#TR
- Mfg. Part Number
- LTC2424IG#TR
- Manufacturer
- Linear
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 20BIT 4CH MICROPWR 28SSOP
- Datasheet Download
- LTC2424IG#TR.pdf
Availability of LTC2424IG#TR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.67826
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC2424IG#TR, we specialize in Linear all series electronic components. LTC2424IG#TR can be shipped within 24 hours after order. If you have any demands for LTC2424IG#TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC2424IG#TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC2424IG#TR
| Internal Part Number | EIS-LTC2424IG#TR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | No Latency Delta Sigma ADCs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | microPOWER™ | |
| Packaging | Tape & Reel (TR) | |
| Number of Bits | 20 | |
| Sampling Rate (Per Second) | 7.5 | |
| Number of Inputs | 4 | |
| Input Type | Single Ended | |
| Data Interface | SPI | |
| Configuration | MUX-ADC | |
| Ratio - S/H:ADC | - | |
| Number of A/D Converters | 1 | |
| Architecture | Sigma-Delta | |
| Reference Type | External | |
| Voltage - Supply, Analog | 2.7 V ~ 5.5 V | |
| Voltage - Supply, Digital | 2.7 V ~ 5.5 V | |
| Features | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 28-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC2424IG#TR | |
| Related Links | LTC242, LTC2424IG#TR Datasheet, Linear Distributor | |
LTC2424IG#TR Details Description
