Linear LTC3220IPF#PBF
- Mfg. Part Number
- LTC3220IPF#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver DC DC Regulator 20mA Backlight 28-UTQFN (4x4) Exposed Pad
- Datasheet Download
- LTC3220IPF#PBF.pdf
Availability of LTC3220IPF#PBF
Available Quantity
5239 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.28000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC3220IPF#PBF, we specialize in Linear all series electronic components. LTC3220IPF#PBF can be shipped within 24 hours after order. If you have any demands for LTC3220IPF#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC3220IPF#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC3220IPF#PBF
| Internal Part Number | EIS-LTC3220IPF#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 91 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | - | |
| Packaging | Tube | |
| Type | DC DC Regulator | |
| Topology | Switched Capacitor (Charge Pump) | |
| Internal Switch(s) | - | |
| Number of Outputs | 18 | |
| Voltage - Supply (Min) | 2.9V | |
| Voltage - Supply (Max) | 5.5V | |
| Voltage - Output | - | |
| Current - Output / Channel | 20mA | |
| Frequency | 850kMz | |
| Dimming | - | |
| Applications | Backlight | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-UFQFN Exposed Pad | |
| Supplier Device Package | 28-UTQFN (4x4) Exposed Pad | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC3220IPF#PBF | |
| Related Links | LTC3220, LTC3220IPF#PBF Datasheet, Linear Distributor | |
LTC3220IPF#PBF Details Description
