Linear LTC3809EDD#TR
- Mfg. Part Number
- LTC3809EDD#TR
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Controllers
- Brief Description
- IC REG CTRLR BUCK PWM CM 10-DFN
- Datasheet Download
- LTC3809EDD#TR.pdf
Availability of LTC3809EDD#TR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.00495
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC3809EDD#TR, we specialize in Linear all series electronic components. LTC3809EDD#TR can be shipped within 24 hours after order. If you have any demands for LTC3809EDD#TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC3809EDD#TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC3809EDD#TR
| Internal Part Number | EIS-LTC3809EDD#TR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Outputs | 1 | |
| Frequency - Max | 825kHz | |
| Duty Cycle | 100% | |
| Voltage - Supply | 2.75 V ~ 9.8 V | |
| Buck | Yes | |
| Boost | No | |
| Flyback | No | |
| Inverting | No | |
| Doubler | No | |
| Divider | No | |
| Cuk | No | |
| Isolated | No | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 10-WFDFN Exposed Pad | |
| Supplier Device Package | 10-DFN (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC3809EDD#TR | |
| Related Links | LTC380, LTC3809EDD#TR Datasheet, Linear Distributor | |
