Linear LTM4603EV-1#PBF
- Mfg. Part Number
- LTM4603EV-1#PBF
- Manufacturer
- Linear
- Product Category
- DC DC Converters
- Brief Description
- IC DC/DC UMODULE 6A 118-LGA
- Datasheet Download
- LTM4603EV-1#PBF.pdf
Availability of LTM4603EV-1#PBF
Available Quantity
5076 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 16.19000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTM4603EV-1#PBF, we specialize in Linear all series electronic components. LTM4603EV-1#PBF can be shipped within 24 hours after order. If you have any demands for LTM4603EV-1#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTM4603EV-1#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTM4603EV-1#PBF
| Internal Part Number | EIS-LTM4603EV-1#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Power Module vs. Discrete DC to DC | |
| Design Resources | LTM4603-1 Spice Model LTM4603EV-1#PBF Footprint.bxl | |
| Featured Product | µModule Products | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 119 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | µModule® | |
| Packaging | Tray | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 20V | |
| Voltage - Output 1 | 0.6 ~ 5 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 6A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 118-LGA | |
| Size / Dimension | 0.59" L x 0.59" W x 0.11" H (15.0mm x 15.0mm x 2.8mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 93% | |
| Power (Watts) - Max | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTM4603EV-1#PBF | |
| Related Links | LTM4603, LTM4603EV-1#PBF Datasheet, Linear Distributor | |
