Linear LTM4620EV#PBF
- Mfg. Part Number
- LTM4620EV#PBF
- Manufacturer
- Linear
- Product Category
- DC DC Converters
- Brief Description
- IC DC/DC UMODULE DUAL 13A 144LGA
- Datasheet Download
- LTM4620EV#PBF.pdf
Availability of LTM4620EV#PBF
Available Quantity
5137 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 36.42010
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTM4620EV#PBF, we specialize in Linear all series electronic components. LTM4620EV#PBF can be shipped within 24 hours after order. If you have any demands for LTM4620EV#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTM4620EV#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTM4620EV#PBF
| Internal Part Number | EIS-LTM4620EV#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | LTM4620 Step-Down µModule Regulator | |
| Video File | LTM4620 | |
| Featured Product | µModule Products | |
| Reference Design Library | DC1498A: 1.2V & 1.5V @ 13A (x2), 4.5 ~ 16V in DC1780A-C: 1.0 ~ 2.5V @ 100A, 4.5 - 16V in | |
| PCN Assembly/Origin | LTM4620 Alternate Source 04/Mar/2015 | |
| Standard Package | 119 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | µModule® | |
| Packaging | Tray | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 16V | |
| Voltage - Output 1 | 0.6 ~ 2.5 V | |
| Voltage - Output 2 | 0.6 ~ 2.5 V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 13A, 13A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | OCP, OVP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 144-LGA | |
| Size / Dimension | 0.59" L x 0.59" W x 0.17" H (15mm x 15mm x 4.32mm) | |
| Operating Temperature | -40°C ~ 125°C | |
| Efficiency | - | |
| Power (Watts) - Max | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTM4620EV#PBF | |
| Related Links | LTM462, LTM4620EV#PBF Datasheet, Linear Distributor | |
LTM4620EV#PBF Details Description
