Lite-On, Inc. LTS-360WC
- Mfg. Part Number
- LTS-360WC
- Manufacturer
- Lite-On, Inc.
- Product Category
- Display Modules - LED Character and Numeric
- Brief Description
- DISPLAY 1DGT RED LC 0.36" CA
- Datasheet Download
- LTS-360WC.pdf
Availability of LTS-360WC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.52500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTS-360WC, we specialize in Lite-On, Inc. all series electronic components. LTS-360WC can be shipped within 24 hours after order. If you have any demands for LTS-360WC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTS-360WC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTS-360WC
| Internal Part Number | EIS-LTS-360WC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 35 | |
| Category | Optoelectronics | |
| Family | Display Modules - LED Character and Numeric | |
| Series | - | |
| Number of Characters | 1 | |
| Size / Dimension | 0.551" H x 0.291" W x 0.332" D (14.00mm x 7.40mm x 8.44mm) | |
| Digit/Alpha Size | 0.36" (9.10mm) | |
| Display Type | 7-Segment | |
| Common Pin | Common Anode | |
| Color | Red | |
| Voltage - Forward (Vf) (Typ) | 1.8V | |
| Current - Test | 20mA | |
| Millicandela Rating | 0.65mcd | |
| Wavelength - Peak | 660nm | |
| Power Dissipation (Max) | 75mW | |
| Package / Case | 10-DIP (0.200", 5.08mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTS-360WC | |
| Related Links | LTS-, LTS-360WC Datasheet, Lite-On, Inc. Distributor | |
LTS-360WC Details Description
