Microsemi Analog Mixed Signal LX1571CDM
- Mfg. Part Number
- LX1571CDM
- Manufacturer
- Microsemi Analog Mixed Signal
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Controllers
- Brief Description
- IC REG CTRLR ISO PWM CM 8-SOIC
- Datasheet Download
- LX1571CDM.pdf
Availability of LX1571CDM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LX1571CDM, we specialize in Microsemi Analog Mixed Signal all series electronic components. LX1571CDM can be shipped within 24 hours after order. If you have any demands for LX1571CDM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LX1571CDM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LX1571CDM
| Internal Part Number | EIS-LX1571CDM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
| Series | - | |
| Packaging | Tube | |
| Number of Outputs | 1 | |
| Frequency - Max | 110kHz | |
| Duty Cycle | 100% | |
| Voltage - Supply | 11 V ~ 25 V | |
| Buck | No | |
| Boost | No | |
| Flyback | No | |
| Inverting | No | |
| Doubler | No | |
| Divider | No | |
| Cuk | No | |
| Isolated | Yes | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LX1571CDM | |
| Related Links | LX15, LX1571CDM Datasheet, Microsemi Analog Mixed Signal Distributor | |
LX1571CDM Details Description
