Lumileds LXR8-SW35
- Mfg. Part Number
- LXR8-SW35
- Manufacturer
- Lumileds
- Product Category
- LED Lighting - White
- Brief Description
- LED LUXEON WARM WHITE 3500K 2SMD
- Datasheet Download
- LXR8-SW35.pdf
Availability of LXR8-SW35
Available Quantity
5514 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.07940
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LXR8-SW35, we specialize in Lumileds all series electronic components. LXR8-SW35 can be shipped within 24 hours after order. If you have any demands for LXR8-SW35, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LXR8-SW35 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LXR8-SW35
| Internal Part Number | EIS-LXR8-SW35 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | LUXEON M and MZ Emitters | |
| Design Resources | Lighting Product Selector | |
| Featured Product | LUXEON M LED | |
| Standard Package | 1 | |
| Category | Optoelectronics | |
| Family | LED Lighting - White | |
| Series | LUXEON M | |
| Packaging | Cut Tape (CT) | |
| Color | White, Warm | |
| CCT (K) | 3500K | |
| Flux @ 85°C, Current - Test | 870 lm (Typ) | |
| Flux @ 25°C, Current - Test | - | |
| Current - Test | 700mA | |
| Voltage - Forward (Vf) (Typ) | 11.2V | |
| Lumens/Watt @ Current - Test | 111 lm/W | |
| CRI (Color Rendering Index) | 80 | |
| Current - Max | 1.2A | |
| Viewing Angle | 120° | |
| Mounting Type | Surface Mount | |
| Package / Case | 2-SMD, No Lead, Exposed Pad | |
| Thermal Resistance of Package | 1.25°C/W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LXR8-SW35 | |
| Related Links | LXR8, LXR8-SW35 Datasheet, Lumileds Distributor | |
LXR8-SW35 Details Description
