NKK Switches M2022TJW03-FA-1A
- Mfg. Part Number
- M2022TJW03-FA-1A
- Manufacturer
- NKK Switches
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER DPDT 6A 125V
- Datasheet Download
- M2022TJW03-FA-1A.pdf
Availability of M2022TJW03-FA-1A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.23000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M2022TJW03-FA-1A, we specialize in NKK Switches all series electronic components. M2022TJW03-FA-1A can be shipped within 24 hours after order. If you have any demands for M2022TJW03-FA-1A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M2022TJW03-FA-1A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M2022TJW03-FA-1A
| Internal Part Number | EIS-M2022TJW03-FA-1A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Switch Basics 3D CAD Models | |
| RoHS Information | Series, Cert of Compliance | |
| 3D Model | M2022TJW03-FA-1A | |
| PCN Design/Specification | M Series Toggles, rockers, Pushbuttons CSA Mark Size 23/Jul/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | M | |
| Packaging | Bulk | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 6A (AC), 4A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Concave (Standard V) | |
| Color - Actuator/Cap | Black | |
| Actuator Marking | No Marking | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | PC Pin | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | Rectangular - 15.90mm x 13.10mm | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | 50,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M2022TJW03-FA-1A | |
| Related Links | M2022TJW, M2022TJW03-FA-1A Datasheet, NKK Switches Distributor | |
