NKK Switches M2032TXW13
- Mfg. Part Number
- M2032TXW13
- Manufacturer
- NKK Switches
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER 3PDT 6A 125V
- Datasheet Download
- M2032TXW13.pdf
Availability of M2032TXW13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.32000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M2032TXW13, we specialize in NKK Switches all series electronic components. M2032TXW13 can be shipped within 24 hours after order. If you have any demands for M2032TXW13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M2032TXW13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M2032TXW13
| Internal Part Number | EIS-M2032TXW13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | M Series Toggles, rockers, Pushbuttons CSA Mark Size 23/Jul/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | M | |
| Packaging | Bulk | |
| Circuit | 3PDT | |
| Switch Function | On-On | |
| Current Rating | 6A (AC), 4A (DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Actuator Arm, Cap Required | |
| Color - Actuator/Cap | - | |
| Actuator Marking | Varies by Cap | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Ingress Protection | - | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | - | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | 50,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M2032TXW13 | |
| Related Links | M2032, M2032TXW13 Datasheet, NKK Switches Distributor | |
