Harwin Inc. M22-2661005
- Mfg. Part Number
- M22-2661005
- Manufacturer
- Harwin Inc.
- Product Category
- Rectangular - Board to Board Connectors - Board Spacers, Stackers
- Brief Description
- 10+10 DIL EXT P/HDR 6MM
- Datasheet Download
- M22-2661005.pdf
Availability of M22-2661005
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M22-2661005, we specialize in Harwin Inc. all series electronic components. M22-2661005 can be shipped within 24 hours after order. If you have any demands for M22-2661005, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M22-2661005 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M22-2661005
| Internal Part Number | EIS-M22-2661005 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Series 09/Jul/2014 | |
| Standard Package | 500 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers | |
| Series | M22 | |
| Packaging | Bulk | |
| Number of Positions | 20 | |
| Pitch | 0.079" (2.00mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.079" (2.00mm) | |
| Length - Overall | 0.469" (11.90mm) | |
| Length - Post (Mating) | 0.138" (3.50mm) | |
| Length - Stack Height | 0.236" (6.00mm) | |
| Length - Tail | 0.095" (2.41mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Contact Finish - Post (Mating) | Gold | |
| Contact Finish Thickness - Post (Mating) | - | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M22-2661005 | |
| Related Links | M22-2, M22-2661005 Datasheet, Harwin Inc. Distributor | |
