Alpha Wire M5503 SL001
- Mfg. Part Number
- M5503 SL001
- Manufacturer
- Alpha Wire
- Product Category
- Multiple Conductor Cables
- Brief Description
- CABLE 15COND 24AWG SHLD 1000'
- Datasheet Download
- M5503 SL001.pdf
Availability of M5503 SL001
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.00000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M5503 SL001, we specialize in Alpha Wire all series electronic components. M5503 SL001 can be shipped within 24 hours after order. If you have any demands for M5503 SL001, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M5503 SL001 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M5503 SL001
| Internal Part Number | EIS-M5503 SL001 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Basics of Wire and Cable | |
| Standard Package | 1 | |
| Category | Cables, Wires | |
| Family | Multiple Conductor Cables | |
| Series | - | |
| Cable Type | Multi-Conductor | |
| Number of Conductors | 15 | |
| Wire Gauge | 24 AWG | |
| Conductor Strand | 7/32 | |
| Conductor Material | Copper, Tinned | |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) | |
| Jacket (Insulation) Diameter | 0.357" (9.06mm) | |
| Shield Type | Foil, Braid | |
| Length | 1000' (304.8m) | |
| Jacket Color | Slate | |
| Ratings | UL Style 2343 | |
| Features | Drain Wire, Rip Cord | |
| Voltage | 300V | |
| Operating Temperature | -20°C ~ 80°C | |
| Usage | - | |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) | |
| Jacket (Insulation) Thickness | 0.063" (1.60mm) | |
| Shield Material | Aluminum; Copper, Tinned | |
| Shield Coverage | 100%, 70% | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M5503 SL001 | |
| Related Links | M5503, M5503 SL001 Datasheet, Alpha Wire Distributor | |
