M/A-Com Technology Solutions MA4SW510B-1
- Mfg. Part Number
- MA4SW510B-1
- Manufacturer
- M/A-Com Technology Solutions
- Product Category
- RF Switches
- Brief Description
- HMIC SP5T PIN SWITCH
- Datasheet Download
- MA4SW510B-1.pdf
Availability of MA4SW510B-1
Available Quantity
5070 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 37.48760
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MA4SW510B-1, we specialize in M/A-Com Technology Solutions all series electronic components. MA4SW510B-1 can be shipped within 24 hours after order. If you have any demands for MA4SW510B-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MA4SW510B-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MA4SW510B-1
| Internal Part Number | EIS-MA4SW510B-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | RF/IF and RFID | |
| Family | RF Switches | |
| Series | HMIC™ | |
| Packaging | Tray - Waffle | |
| Frequency - Lower | 2GHz | |
| Frequency - Upper | 18GHz | |
| Isolation @ Frequency | 35dB @ 18GHz (typ) | |
| Insertion Loss @ Frequency | 1.8dB @ 18GHz | |
| IIP3 | - | |
| Topology | Reflective | |
| Circuit | SP5T | |
| P1dB | - | |
| Features | - | |
| Impedance | - | |
| Operating Temperature | -65°C ~ 125°C | |
| Voltage - Supply | - | |
| RF Type | General Purpose | |
| Package / Case | Die | |
| Supplier Device Package | Die | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MA4SW510B-1 | |
| Related Links | MA4SW, MA4SW510B-1 Datasheet, M/A-Com Technology Solutions Distributor | |
MA4SW510B-1 Details Description
