Maxim Integrated MAX2830ETM+
- Mfg. Part Number
- MAX2830ETM+
- Manufacturer
- Maxim Integrated
- Product Category
- RF Transceiver ICs
- Brief Description
- IC TXRX RF W/PA AND SW 48-TQFN
- Datasheet Download
- MAX2830ETM+.pdf
Availability of MAX2830ETM+
Available Quantity
5496 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.02350
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MAX2830ETM+, we specialize in Maxim Integrated all series electronic components. MAX2830ETM+ can be shipped within 24 hours after order. If you have any demands for MAX2830ETM+, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MAX2830ETM+ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MAX2830ETM+
| Internal Part Number | EIS-MAX2830ETM+ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Reference Design for an 802.11b/g RF Front-End Module Using the MAX2830 WLAN Reference Design with the MAX2830 Demonstrating Green Technology with Apples, Oranges, Lemons, and Limes Improve Sensor Performance and SNR in Pulse Oximeter Designs Introduction to Hearing Aids and Important Design Considerations General Layout Guidelines for RF and Mixed-Signal PCBs | |
| Product Training Modules | Lead (SnPb) Finish for COTS Long-Term Supply Program | |
| Design Resources | Development Tool Selector | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 86 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver ICs | |
| Series | - | |
| Packaging | Tube | |
| Type | TxRx Only | |
| RF Family/Standard | WiFi | |
| Protocol | 802.11b/g | |
| Modulation | - | |
| Frequency | 2.4GHz ~ 2.5GHz | |
| Data Rate (Max) | 54Mbps | |
| Power - Output | 17.1dBm | |
| Sensitivity | -75dBm | |
| Memory Size | - | |
| Serial Interfaces | SPI | |
| GPIO | - | |
| Voltage - Supply | 2.7 V ~ 3.6 V | |
| Current - Receiving | 62mA | |
| Current - Transmitting | 82mA | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 48-WFQFN Exposed Pad | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MAX2830ETM+ | |
| Related Links | MAX28, MAX2830ETM+ Datasheet, Maxim Integrated Distributor | |
MAX2830ETM+ Details Description
