Texas Instruments MAX3232CPWG4
- Mfg. Part Number
- MAX3232CPWG4
- Manufacturer
- Texas Instruments
- Product Category
- Interface - Drivers, Receivers, Transceivers
- Brief Description
- IC DRVR/RX MULTCH RS232 16TSSOP
- Datasheet Download
- MAX3232CPWG4.pdf
Availability of MAX3232CPWG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.50000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MAX3232CPWG4, we specialize in Texas Instruments all series electronic components. MAX3232CPWG4 can be shipped within 24 hours after order. If you have any demands for MAX3232CPWG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MAX3232CPWG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MAX3232CPWG4
| Internal Part Number | EIS-MAX3232CPWG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 90 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Drivers, Receivers, Transceivers | |
| Series | - | |
| Packaging | Tube | |
| Type | Transceiver | |
| Protocol | RS232 | |
| Number of Drivers/Receivers | 2/2 | |
| Duplex | Full | |
| Receiver Hysteresis | 300mV | |
| Data Rate | 250kbps | |
| Voltage - Supply | 3 V ~ 5.5 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 16-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MAX3232CPWG4 | |
| Related Links | MAX323, MAX3232CPWG4 Datasheet, Texas Instruments Distributor | |
MAX3232CPWG4 Details Description
