Texas Instruments MAX3232IDWRG4
.jpg)
- Mfg. Part Number
- MAX3232IDWRG4
- Manufacturer
- Texas Instruments
- Product Category
- Interface - Drivers, Receivers, Transceivers
- Brief Description
- IC DRVR/RCVR MULTCH RS232 16SOIC
- Datasheet Download
- MAX3232IDWRG4.pdf
Availability of MAX3232IDWRG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.94500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MAX3232IDWRG4, we specialize in Texas Instruments all series electronic components. MAX3232IDWRG4 can be shipped within 24 hours after order. If you have any demands for MAX3232IDWRG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MAX3232IDWRG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MAX3232IDWRG4
| Internal Part Number | EIS-MAX3232IDWRG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Drivers, Receivers, Transceivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Transceiver | |
| Protocol | RS232 | |
| Number of Drivers/Receivers | 2/2 | |
| Duplex | Full | |
| Receiver Hysteresis | 300mV | |
| Data Rate | 250kbps | |
| Voltage - Supply | 3 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 16-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MAX3232IDWRG4 | |
| Related Links | MAX323, MAX3232IDWRG4 Datasheet, Texas Instruments Distributor | |
