Maxim Integrated MAX3465ESD+
- Mfg. Part Number
- MAX3465ESD+
- Manufacturer
- Maxim Integrated
- Product Category
- Interface - Drivers, Receivers, Transceivers
- Brief Description
- IC TXRX RS485/422 14-SOIC
- Datasheet Download
- MAX3465ESD+.pdf
Availability of MAX3465ESD+
Available Quantity
5716 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.47360
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MAX3465ESD+, we specialize in Maxim Integrated all series electronic components. MAX3465ESD+ can be shipped within 24 hours after order. If you have any demands for MAX3465ESD+, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MAX3465ESD+ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MAX3465ESD+
| Internal Part Number | EIS-MAX3465ESD+ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | RS-485 (EIA/TIA-485) Differential Data Transmission System Basics | |
| Product Training Modules | Lead (SnPb) Finish for COTS Long-Term Supply Program | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 100 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Drivers, Receivers, Transceivers | |
| Series | - | |
| Packaging | Tube | |
| Type | Transceiver | |
| Protocol | RS422, RS485 | |
| Number of Drivers/Receivers | 1/1 | |
| Duplex | Full | |
| Receiver Hysteresis | 50mV | |
| Data Rate | 40Mbps | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 14-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MAX3465ESD+ | |
| Related Links | MAX34, MAX3465ESD+ Datasheet, Maxim Integrated Distributor | |
MAX3465ESD+ Details Description
