Maxim Integrated MAX4420CSA
- Mfg. Part Number
- MAX4420CSA
- Manufacturer
- Maxim Integrated
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC DRIVER MOSFET 6A HS 8-SOIC
- Datasheet Download
- MAX4420CSA.pdf
Availability of MAX4420CSA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MAX4420CSA, we specialize in Maxim Integrated all series electronic components. MAX4420CSA can be shipped within 24 hours after order. If you have any demands for MAX4420CSA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MAX4420CSA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MAX4420CSA
| Internal Part Number | EIS-MAX4420CSA | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Lead (SnPb) Finish for COTS Long-Term Supply Program | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Configuration | Low-Side | |
| Input Type | Non-Inverting | |
| Delay Time | 35ns | |
| Current - Peak | 6A | |
| Number of Configurations | 1 | |
| Number of Outputs | 1 | |
| High Side Voltage - Max (Bootstrap) | - | |
| Voltage - Supply | 4.5 V ~ 18 V | |
| Operating Temperature | 0°C ~ 70°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC N | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MAX4420CSA | |
| Related Links | MAX44, MAX4420CSA Datasheet, Maxim Integrated Distributor | |
