Maxim Integrated MAX7031MATJ50+
- Mfg. Part Number
- MAX7031MATJ50+
- Manufacturer
- Maxim Integrated
- Product Category
- RF Transceiver ICs
- Brief Description
- IC TXRX FSK W/PLL 32TQFN
- Datasheet Download
- MAX7031MATJ50+.pdf
Availability of MAX7031MATJ50+
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MAX7031MATJ50+, we specialize in Maxim Integrated all series electronic components. MAX7031MATJ50+ can be shipped within 24 hours after order. If you have any demands for MAX7031MATJ50+, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MAX7031MATJ50+ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MAX7031MATJ50+
| Internal Part Number | EIS-MAX7031MATJ50+ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Automotive Product Guide | |
| Mfg Application Notes | Requirements of Remote Keyless Entry (RKE) Systems FCC and ETSI Requirements for Short-Range UHF ASK-Modulated Transmitters Power Amplifier Theory for High-Efficiency Low-Cost ISM-Band Transmitters Radiated Power and Field Strength from UHF ISM Transmitters Avoid PC-Layout "Gotchas" in ISM-RF Products Important Design Considerations for Heart-Rate and Fitness Monitors Introduction to Hearing Aids and Important Design Considerations General Layout Guidelines for RF and Mixed-Signal PCBs Radio Link-Budget Calculations for ISM-RF Products Design a Crystal Oscillator to Match Your Application RF Basics How to Optimize an ISM Radio Frequency (RF) System Crystal Calculations for ISM-RF Products Baseband Calculations for ISM-RF Receivers Squelch in ISM-RF Receivers | |
| Product Training Modules | Lead (SnPb) Finish for COTS Long-Term Supply Program | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver ICs | |
| Series | - | |
| Packaging | Tube | |
| Type | TxRx Only | |
| RF Family/Standard | General ISM/SRD < 1GHz | |
| Protocol | - | |
| Modulation | FSK | |
| Frequency | 308MHz, 315MHz, 433.92MHz | |
| Data Rate (Max) | 33kbps | |
| Power - Output | 10dBm | |
| Sensitivity | -110dBm | |
| Memory Size | - | |
| Serial Interfaces | - | |
| GPIO | - | |
| Voltage - Supply | 2.1 V ~ 3.6 V | |
| Current - Receiving | 6.7mA | |
| Current - Transmitting | 12.5mA | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 32-WFQFN Exposed Pad | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MAX7031MATJ50+ | |
| Related Links | MAX7031, MAX7031MATJ50+ Datasheet, Maxim Integrated Distributor | |
MAX7031MATJ50+ Details Description
