C&K Components MB03L2NZGF
- Mfg. Part Number
- MB03L2NZGF
- Manufacturer
- C&K Components
- Product Category
- Rotary Switches
- Brief Description
- SWITCH ROTARY
- Datasheet Download
- MB03L2NZGF.pdf
Availability of MB03L2NZGF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 14.46540
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MB03L2NZGF, we specialize in C&K Components all series electronic components. MB03L2NZGF can be shipped within 24 hours after order. If you have any demands for MB03L2NZGF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MB03L2NZGF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MB03L2NZGF
| Internal Part Number | EIS-MB03L2NZGF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rotary Switches | |
| Series | M | |
| Number of Positions | 3 | |
| Index Stops | Fixed | |
| Number of Decks | 1 | |
| Number of Poles per Deck | 2 | |
| Circuit per Deck | DP3T | |
| Contact Timing | Non-Shorting (BBM) | |
| Current Rating | 250mA (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 28V | |
| Actuator Type | Screwdriver Slot | |
| Actuator Length | Flush | |
| Angle of Throw | 36° | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Mounting Type | Panel Mount | |
| Termination Style | Solder Lug | |
| Features | IP67 - Dust Tight, Waterproof | |
| Depth Behind Panel | 14.86mm | |
| Panel Cutout Dimensions | Circular - 6.60mm Dia | |
| Operating Force, Torque | 4 ~ 7 in-oz | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MB03L2NZGF | |
| Related Links | MB03L, MB03L2NZGF Datasheet, C&K Components Distributor | |
MB03L2NZGF Details Description
