ON Semiconductor MBR1090
- Mfg. Part Number
- MBR1090
- Manufacturer
- ON Semiconductor
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 90V 10A TO220-2
- Datasheet Download
- MBR1090.pdf
Availability of MBR1090
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MBR1090, we specialize in ON Semiconductor all series electronic components. MBR1090 can be shipped within 24 hours after order. If you have any demands for MBR1090, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MBR1090 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MBR1090
| Internal Part Number | EIS-MBR1090 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 03/Jan/2008 | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | SWITCHMODE™ | |
| Packaging | Tube | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 90V | |
| Current - Average Rectified (Io) | 10A | |
| Voltage - Forward (Vf) (Max) @ If | 800mV @ 10A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 100µA @ 90V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-2 | |
| Supplier Device Package | TO-220-2 | |
| Operating Temperature - Junction | -65°C ~ 175°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MBR1090 | |
| Related Links | MBR, MBR1090 Datasheet, ON Semiconductor Distributor | |
MBR1090 Details Description
