ON Semiconductor MBR120ESFT3
- Mfg. Part Number
- MBR120ESFT3
- Manufacturer
- ON Semiconductor
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 20V 1A SOD123L
- Datasheet Download
- MBR120ESFT3.pdf
Availability of MBR120ESFT3
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MBR120ESFT3, we specialize in ON Semiconductor all series electronic components. MBR120ESFT3 can be shipped within 24 hours after order. If you have any demands for MBR120ESFT3, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MBR120ESFT3 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MBR120ESFT3
| Internal Part Number | EIS-MBR120ESFT3 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 20V | |
| Current - Average Rectified (Io) | 1A | |
| Voltage - Forward (Vf) (Max) @ If | 530mV @ 1A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 10µA @ 20V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Surface Mount | |
| Package / Case | SOD-123F | |
| Supplier Device Package | SOD-123L | |
| Operating Temperature - Junction | -65°C ~ 150°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MBR120ESFT3 | |
| Related Links | MBR12, MBR120ESFT3 Datasheet, ON Semiconductor Distributor | |
MBR120ESFT3 Details Description
