ON Semiconductor MBR540MFST3G
- Mfg. Part Number
- MBR540MFST3G
- Manufacturer
- ON Semiconductor
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 40V 5A 5DFN
- Datasheet Download
- MBR540MFST3G.pdf
Availability of MBR540MFST3G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.17328
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MBR540MFST3G, we specialize in ON Semiconductor all series electronic components. MBR540MFST3G can be shipped within 24 hours after order. If you have any demands for MBR540MFST3G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MBR540MFST3G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MBR540MFST3G
| Internal Part Number | EIS-MBR540MFST3G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 40V | |
| Current - Average Rectified (Io) | 5A | |
| Voltage - Forward (Vf) (Max) @ If | 580mV @ 5A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 2mA @ 40V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerTDFN, 5 Leads | |
| Supplier Device Package | 5-DFN, 8-SO Flat Lead (5x6) | |
| Operating Temperature - Junction | -40°C ~ 175°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MBR540MFST3G | |
| Related Links | MBR540, MBR540MFST3G Datasheet, ON Semiconductor Distributor | |
