ON Semiconductor MBRB20100CTT4G
- Mfg. Part Number
- MBRB20100CTT4G
- Manufacturer
- ON Semiconductor
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE ARRAY SCHOTTKY 100V D2PAK
- Datasheet Download
- MBRB20100CTT4G.pdf
Availability of MBRB20100CTT4G
Available Quantity
7800 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.14840
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MBRB20100CTT4G, we specialize in ON Semiconductor all series electronic components. MBRB20100CTT4G can be shipped within 24 hours after order. If you have any demands for MBRB20100CTT4G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MBRB20100CTT4G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MBRB20100CTT4G
| Internal Part Number | EIS-MBRB20100CTT4G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | SWITCHMODE™ | |
| Packaging | Cut Tape (CT) | |
| Diode Configuration | 1 Pair Common Cathode | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 100V | |
| Current - Average Rectified (Io) (per Diode) | 10A | |
| Voltage - Forward (Vf) (Max) @ If | 850mV @ 10A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 100µA @ 100V | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | D2PAK | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MBRB20100CTT4G | |
| Related Links | MBRB201, MBRB20100CTT4G Datasheet, ON Semiconductor Distributor | |
MBRB20100CTT4G Details Description
