Vishay Semiconductor/Diodes Division MBRB20H35CT-E3/45
- Mfg. Part Number
- MBRB20H35CT-E3/45
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes, Rectifiers - Arrays
- Brief Description
- DIODE ARRAY SCHOTTKY 35V TO263AB
- Datasheet Download
- MBRB20H35CT-E3/45.pdf
Availability of MBRB20H35CT-E3/45
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.66885
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MBRB20H35CT-E3/45, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. MBRB20H35CT-E3/45 can be shipped within 24 hours after order. If you have any demands for MBRB20H35CT-E3/45, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MBRB20H35CT-E3/45 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MBRB20H35CT-E3/45
| Internal Part Number | EIS-MBRB20H35CT-E3/45 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Video File | Functions & Parameters of the “Simplest” Semiconductor | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Arrays | |
| Series | - | |
| Packaging | Tube | |
| Diode Configuration | 1 Pair Common Cathode | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 35V | |
| Current - Average Rectified (Io) (per Diode) | 10A | |
| Voltage - Forward (Vf) (Max) @ If | 850mV @ 20A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 100µA @ 35V | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | TO-263AB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MBRB20H35CT-E3/45 | |
| Related Links | MBRB20H3, MBRB20H35CT-E3/45 Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
