ON Semiconductor MC100EPT23DTR2G
- Mfg. Part Number
- MC100EPT23DTR2G
- Manufacturer
- ON Semiconductor
- Product Category
- Logic - Translators, Level Shifters
- Brief Description
- IC XLATOR LV PECL-TTL DL 8-TSSOP
- Datasheet Download
- MC100EPT23DTR2G.pdf
Availability of MC100EPT23DTR2G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.51000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC100EPT23DTR2G, we specialize in ON Semiconductor all series electronic components. MC100EPT23DTR2G can be shipped within 24 hours after order. If you have any demands for MC100EPT23DTR2G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC100EPT23DTR2G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC100EPT23DTR2G
| Internal Part Number | EIS-MC100EPT23DTR2G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Translators, Level Shifters | |
| Series | 100EPT | |
| Packaging | Tape & Reel (TR) | |
| Translator Type | Mixed Signal | |
| Channel Type | Unidirectional | |
| Number of Circuits | 1 | |
| Channels per Circuit | 2 | |
| Voltage - VCCA | - | |
| Voltage - VCCB | - | |
| Input Signal | CML, LVDS, LVPECL | |
| Output Signal | LVTTL, LVCMOS | |
| Output Type | Non-Inverted | |
| Data Rate | - | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Features | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | |
| Supplier Device Package | 8-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC100EPT23DTR2G | |
| Related Links | MC100EP, MC100EPT23DTR2G Datasheet, ON Semiconductor Distributor | |
MC100EPT23DTR2G Details Description
