Integrated Device Technology (IDT) MC100ES6056EJR2
.jpg)
- Mfg. Part Number
- MC100ES6056EJR2
- Manufacturer
- Integrated Device Technology (IDT)
- Product Category
- Clock/Timing - Clock Buffers, Drivers
- Brief Description
- IC CLK MULTIPLX 2:1 3GHZ 20TSSOP
- Datasheet Download
- MC100ES6056EJR2.pdf
Availability of MC100ES6056EJR2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC100ES6056EJR2, we specialize in Integrated Device Technology (IDT) all series electronic components. MC100ES6056EJR2 can be shipped within 24 hours after order. If you have any demands for MC100ES6056EJR2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC100ES6056EJR2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC100ES6056EJR2
| Internal Part Number | EIS-MC100ES6056EJR2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 14/Jun/2013 | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Clock/Timing - Clock Buffers, Drivers | |
| Series | 100ES | |
| Packaging | Tape & Reel (TR) | |
| Type | Multiplexer | |
| Number of Circuits | 2 | |
| Ratio - Input:Output | 2:1 | |
| Differential - Input:Output | Yes/Yes | |
| Input | ECL, LVDS, PECL | |
| Output | ECL, LVDS, PECL | |
| Frequency - Max | 3GHz | |
| Voltage - Supply | ±2.375 V ~ 3.8 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 20-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC100ES6056EJR2 | |
| Related Links | MC100ES, MC100ES6056EJR2 Datasheet, Integrated Device Technology (IDT) Distributor | |
MC100ES6056EJR2 Details Description
