ON Semiconductor MC33362DW
- Mfg. Part Number
- MC33362DW
- Manufacturer
- ON Semiconductor
- Product Category
- PMIC - AC DC Converters, Offline Switchers
- Brief Description
- IC SWIT PWM OVP UVLO HV 16SOIC
- Datasheet Download
- MC33362DW.pdf
Availability of MC33362DW
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC33362DW, we specialize in ON Semiconductor all series electronic components. MC33362DW can be shipped within 24 hours after order. If you have any demands for MC33362DW, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC33362DW Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC33362DW
| Internal Part Number | EIS-MC33362DW | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 03/Jan/2008 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 47 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - AC DC Converters, Offline Switchers | |
| Series | - | |
| Packaging | Tube | |
| Output Isolation | Isolated | |
| Internal Switch(s) | Yes | |
| Voltage - Breakdown | 500V | |
| Topology | Flyback, Forward | |
| Voltage - Start Up | 14.5V | |
| Voltage - Supply (Vcc/Vdd) | 9.5 V ~ 40 V | |
| Duty Cycle | 50% | |
| Frequency - Switching | 67.5kHz ~ 285kHz | |
| Power (Watts) | - | |
| Fault Protection | Current Limiting, Over Temperature, Over Voltage | |
| Control Features | Frequency Control | |
| Operating Temperature | -25°C ~ 150°C (TJ) | |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) 13 leads | |
| Supplier Device Package | 16-SOIC W | |
| Mounting Type | Surface Mount | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC33362DW | |
| Related Links | MC33, MC33362DW Datasheet, ON Semiconductor Distributor | |
