ON Semiconductor MC74AC541DTR2
- Mfg. Part Number
- MC74AC541DTR2
- Manufacturer
- ON Semiconductor
- Product Category
- Logic - Buffers, Drivers, Receivers, Transceivers
- Brief Description
- IC BUFF/DVR TRI-ST 8BIT 20TSSOP
- Datasheet Download
- MC74AC541DTR2.pdf
Availability of MC74AC541DTR2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC74AC541DTR2, we specialize in ON Semiconductor all series electronic components. MC74AC541DTR2 can be shipped within 24 hours after order. If you have any demands for MC74AC541DTR2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC74AC541DTR2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC74AC541DTR2
| Internal Part Number | EIS-MC74AC541DTR2 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 24/Jan/2011 | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Buffers, Drivers, Receivers, Transceivers | |
| Series | 74AC | |
| Packaging | Tape & Reel (TR) | |
| Logic Type | Buffer/Line Driver, Non-Inverting | |
| Number of Elements | 1 | |
| Number of Bits per Element | 8 | |
| Current - Output High, Low | 24mA, 24mA | |
| Voltage - Supply | 2 V ~ 6 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 20-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC74AC541DTR2 | |
| Related Links | MC74AC, MC74AC541DTR2 Datasheet, ON Semiconductor Distributor | |
MC74AC541DTR2 Details Description
