ON Semiconductor MC74HC1G32DFT2G
- Mfg. Part Number
- MC74HC1G32DFT2G
- Manufacturer
- ON Semiconductor
- Product Category
- Logic - Gates and Inverters
- Brief Description
- IC GATE OR 1CH 2-INP SC-70
- Datasheet Download
- MC74HC1G32DFT2G.pdf
Availability of MC74HC1G32DFT2G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.04301
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC74HC1G32DFT2G, we specialize in ON Semiconductor all series electronic components. MC74HC1G32DFT2G can be shipped within 24 hours after order. If you have any demands for MC74HC1G32DFT2G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC74HC1G32DFT2G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC74HC1G32DFT2G
| Internal Part Number | EIS-MC74HC1G32DFT2G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | SC88/A Copper Wire 17/Jun/2011 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Gates and Inverters | |
| Series | 74HC | |
| Packaging | Tape & Reel (TR) | |
| Logic Type | OR Gate | |
| Number of Circuits | 1 | |
| Number of Inputs | 2 | |
| Features | - | |
| Voltage - Supply | 2 V ~ 6 V | |
| Current - Quiescent (Max) | 1µA | |
| Current - Output High, Low | 2.6mA, 2.6mA | |
| Logic Level - Low | 0.5 V ~ 1.8 V | |
| Logic Level - High | 1.5 V ~ 4.2 V | |
| Max Propagation Delay @ V, Max CL | 17ns @ 6V, 50pF | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Supplier Device Package | SC-70 | |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC74HC1G32DFT2G | |
| Related Links | MC74HC1, MC74HC1G32DFT2G Datasheet, ON Semiconductor Distributor | |
MC74HC1G32DFT2G Details Description
